¶ Using AVR with External Asterisk PBX
This guide explains how to configure Asterisk PBX so that calls are sent to AVR Core via the AudioSocket channel driver.
¶ Prerequisites
Before proceeding, ensure you have:
- A working Asterisk PBX installation.
- The AudioSocket channel driver installed and enabled in Asterisk.
- The IP address and port of your AVR Core instance (e.g.,
192.168.1.100:6000). - The
uuidgencommand available on your system (usually pre-installed on Linux).
¶ Editing extensions.conf
Asterisk dial plans are configured in the extensions.conf file.
By default, this file is located in:
/etc/asterisk/extensions.conf
¶ Basic Configuration
Option 1 – Direct AudioSocket Connection:
same => n,AudioSocket(${UUID},IP_AVR_CORE:PORT_AVR_CORE)`
Option 2 – Recommended for scalability (Dial syntax):
same => n,Dial(AudioSocket/IP_AVR_CORE:PORT_AVR_CORE/${UUID})
The Dial method is recommended because it integrates better with Asterisk’s native call handling, enabling more flexible call routing and scalability.
¶ Example: extensions.conf
Below is a minimal working example that answers a call, generates a UUID, and connects it to AVR Core.
[avr-context]
exten => 5001,1,Answer()
same => n,Ringing()
same => n,Wait(1)
same => n,Set(UUID=${SHELL(uuidgen | tr -d '\n')})
same => n,Dial(AudioSocket/IP_AVR_CORE:PORT_AVR_CORE/${UUID})
same => n,Hangup()
Explanation:
- exten => 5001,1,Answer() → Answers the incoming call.
- Wait(1) → Adds a short delay to ensure the call is stable before connecting.
- Set(UUID=...) → Creates a unique identifier for the session, used by AVR Core to track the call.
- Dial(...) → Connects to AVR Core using AudioSocket.
- Hangup() → Ends the call when AVR Core terminates the session.
¶ Reloading Asterisk
After editing extensions.conf, reload the Asterisk dialplan:
asterisk -rx "dialplan reload"
¶ Testing
- Dial 5001 (or the extension you configured) from any endpoint connected to your Asterisk PBX.
- The call should route to AVR Core and start interacting via your configured ASR/LLM/TTS or STS modules.
- Check Asterisk logs for troubleshooting:
asterisk -rvvvvv
Tip: For production deployments, you may want to place AVR Core on a dedicated network interface or behind a load balancer for better scalability.
